BA-PF-25L auto Powder Filling Machine

This is an automatic linear type filling machine, for powder or small granule product.Some common products such as flour, protein powder, sugar, talcum powder, pharmaceutic powder, dye etc.The package can be buckets, bottles, jars, cans, vials, canisters etc.

Product Name :
BA-PF-25L auto Powder Filling Machine
Certification :
cGMP CE ISO SGS and etc.
Lead Time :
15 Days Fast Delivery.
Loading Port :
Guangzhou/Shenzhen / Shanghai
Product Function :
1l-25L
After-Sales Provided :
Engineers available to service machinery overseas.
Warranty :
1 Years
MOQ :
1

Inquire Now

Product Details

Overview

The machine can do dosing and filling work. Due to the special professional design, so it is suitable to the fluidic or low-fluidity materials, like coffee powder, wheat flour, condiment, solid drink, veterinary drugs, dextrose, pharmaceuticals, powder additive, talcum powder, agriculture pesticide, dyestuff, and so on.

Main Features

l Lathing auger screw to guarantee the precise filling accuracy

l PLC control and touch screen display

l Servo motor drives screw to guarantee stable performance

l Quick disconnecting hopper could be washed easily without tools

l Can be setting to semi-auto filling by pedal switch or auto filling

l Full stainless steel 304 material

l weight feedback and proportion track to materials, which overcomes difficulties of filling weight changes due to materials’ density change.

l Save 20 sets of formula inside the machine for later use

l Replacing the auger parts, different products ranging from fine powder to granule and different weight can be packed

l Multi language interface

Main Technical Parameters

Model	BA-PF-A21
Control system	PLC & Touch Screen
Hopper	25L
Packing Weight	1 - 500g
Weight dosing	By auger
Packing Accuracy	≤ 100g, ≤±2%; 100 –500g, ≤±1%
Filling Speed	40 – 120 times per min
Power Supply	3P AC208-415V 50/60Hz
Total Power	1.2 KW
Total Weight	160kg
Overall Dimensions	1500×760×1850mm
